9U Wall Mount Cabinet - 201 Series, 24 Inches Deep, Flat Packed

by Networx
Get organized with the 9U 201 Series of Wall Mount Cabinets from Networx®... read more
SKU: WMC-S201-9U
GTIN: 00845425023131
Manufacturer: Networx
In stock
$189.49
Volume Discounts
Quantity 2+ 10+ 25+
Price $185.70 $181.91 $178.12
Description

Get organized with the 9U 201 Series of Wall Mount Cabinets from Networx®. This cabinet comes equipped with some of the most requested features. Starting with the basics, this Wall Mount Cabinet is constructed with high quality SPCC Cold-Rolled Steel Panels. All Networx® Wall Mount Cabinets come with removable side panels, which include vents to keep equipment cool, to allow for quick access to sensitive networking equipment. All front panels swing out for easy access to loaded network equipment and include a window of 5mm Clear Acrylic. Included with this high quality Wall Mount Cabinet is a single 120mm fan for ideal air movement to keep network equipment cool and running at peak performance. Adjustable rails allow for full customization to allow a variety of networking equipment to fit securely. The rails are punched to allow for the installation of M6 Cage Nuts. Both Side Panels and Front Door are lockable with the included set of keys. Top/Bottom/Rear knockouts for cable entry and exit. All racks are designed to house 19" rack mountable equipment.

  • 12 M6 Cage Nuts
  • 9U Rack Mount Units
  • External Dimensions: Height 19.8" x Width 24" x Depth 24"
  • Designed for equipment with a 19" mounting profile
  • Vented Top/Sides/Front Panels for adequate airflow
  • Reversible front door with Clear Acrylic window
  • Removable side panels for easy access to equipment
  • Front and Side Panels are lockable with included set of keys
  • Top/Bottom/Real Knockouts for easy cable entry and exit
  • Supports up to 130lbs when secured properly
  • Flat Packed - Assembly Required
Additional Resources
Customer Reviews
4.6 out of 5

Based on 8 reviews
5 star
75%
4 star
12%
3 star
12%
2 star
0%
1 star
0%
Kelley
Great product and service
RMU: 12U Verified Purchase
Very nice wall-mounted cabinet, came well packaged and easy to assemble. Very sturdy. Great price point. Bonus points to the CSR who changed my shipping to a "gentler" option at no additional cost to avoid damage. Love this company and the Networx Line
Guest
Understand the limitations
RMU: 18U
The 18U cabinet was what we needed due to height limitations in a recent install, and was the only cabinet I could find that fit the bill. Unfortunately the weight capacity is optimistic at best. We added a 45 lb UPS unit in the bottom of the cabinet, and found that the side panels needed to be in place to maintain the structural integrity of the cabinet. It could be easily addressed by the manufacturer if they added a couple of diagonal braces inside the cabinet, but I would say the practical limit is more like 50 lbs of gear max. Otherwise it is a decent cabinet.
Michael
Excellent cabinet
RMU: 12U Verified Purchase
Bang for yourself buck. Quality is great almost didn’t believe it.
Keith
Great Product - Fair Price
RMU: 18U Verified Purchase
This is a well built cabinet with lots of unexpected features. Not only is it made of heavy gauge metal it’s vented side doors and smoked glass front door make it a pleasing addition to any office. This exact cabinet was used in a work room to clean up some network equipment that grew over time and got out of hand but after the installation it looks quite nice (and much quieter). I also added an additional fan to the one that comes standard for better ventilation and a half shelf for some smaller items.
Juan Carlos
Good case, instructions to assembly are not very clear
RMU: 6U Verified Purchase
This is a very good case to fit a HikVision NVR, is deep enough to hold the unit. Has also nice side doors and good overall quality. Only reason I won't give five stars is for poor assembly instructions.
Products specifications
Cage Nut Rails Front & Rear
Color Black
Internal Mounting Format 19"
Key Lock Set (2 Keys per Set) 1 Set
Load Capacity 130 lbs
Locking Side Panels Yes
Manufacturer Networx®
Preinstalled 80CFM 110V Fans 1
Rack Size Depth (Internal) 24" (20")
Rack Size Width (Internal) 24" (19")
Reinforced Door Frame Yes
RMU 9U
Structure & Fabrication SPCC Cold-Rolled Steel Sheets
Vented Side Panels Removable
Hinged Swing Out Design No
Delivery Style Flat Packed
Door Style Clear Acrylic
Color Gray
Key Lock Set (2 Keys per Set) 2 Set
Revision Rev. 3
Rack Height (Assembled) 19.8 Inch
SKU WMC-S201-9U
GTIN 00845425023131
Weight (Lbs) 51.00
