12U Swing Out Wall Mount Cabinet - 501 Series, 24 Inches Deep, Flat Packed

by Networx®
Get Organized with this Flat Packed 12U Swing Out Wall Mount Cabinet from Networx®... read more
SKU: WMC-S501-12U
GTIN: 00845425024763
Manufacturer: Networx®
RMU Options:
RMU 6U 6U RMU 9U 9U
RMU 12U 12U
RMU 15U 15U
In stock
$198.94
$210.94 (5% off)
Volume Discounts
Quantity 2+ 10+ 25+
Price $194.96 $190.98 $187.00
Description

Get organized with the 12U 501 Series of Swing Out Wall Mount Cabinets from Networx®. The Swing Out style of cabients allows for the rear door of the cabinet to open up and allow even greater flexibility and access. In addition, the rear swingout panel is reversible and can swing out from the left or right. This cabinet comes equipped with some of the most requested features. Starting with the basics, this Wall Mount Cabinet is constructed with high quality SPCC Cold-Rolled Steel Panels. All Networx® Wall Mount Cabinets come with removable side panels, which include vents to keep equipment cool, to allow for quick access to sensitive networking equipment. All front panels swing out for easy access to loaded network equipment and include a window of 5mm tempered glass. Included with this high quality Wall Mount Cabinet is a single 120mm fan for ideal air movement to keep network equipment cool and running at peak performance. Adjustable rails allow for full customization to allow a variety of networking equipment to fit securely. The rails are punched to allow for the installation of M6 Cage Nuts. The Side Panels, Rear Panel and Front Door are lockable with the included set of keys. Top/Bottom/Rear knockouts for cable entry and exit. All racks are designed to house 19" rack mountable equipment.

  • 12 M6 Cage Nuts
  • 4 Lag Bolts for Wall Mounting
  • 12U Rack Mount Units
  • Designed for equipment with a 19" mounting profile
  • Vented Top/Sides/Front Panels for adequate airflow
  • Reversible front door with tempered glass window
  • Reversible rear panel allows for swingout to the left or right
  • Removable side panels for easy access to equipment
  • Front, Rear and Side Panels are lockable with included set of keys
  • Top/Bottom/Rear Knockouts for easy cable entry and exit
  • Supports up to 130lbs when secured properly
  • Flat Packed
  • Mounting Template Included
Additional Resources
Related Videos
How to mount a Wall Mount Cabinet How to mount a Wall Mount Cabinet
Products specifications
Cage Nut Rails Front & Rear
Color Black
Internal Mounting Format 19"
Key Lock Set (2 Keys per Set) 3 Sets
Load Capacity 130 lbs
Locking Side Panels Yes
Manufacturer Networx®
Rack Size Width (Internal) 24" (19")
Reinforced Door Frame Yes
Door Style Tempered Glass
RMU 12U
Structure & Fabrication SPCC Cold-Rolled Steel Sheets
Vented Side Panels Removable
Hinged Swing Out Design Yes
Rack Size Depth (Internal) 24" (19")
Preinstalled 80CFM 110V Fans 1
Rack Height (Assembled) 26.4 Inch
Delivery Style Flat Packed
SKU WMC-S501-12U
GTIN 00845425024763
Weight (Lbs) 60.75
