16 Port 3-User (1-Local, 2-Remote) Network KVM

The KN2116 is a sixteen port over- the- net KVM allowing a three users to simultaneous log on and independently control computers on three separate ports. Network control can be from any workstation on your LAN or WAN, or from the Internet. The KN2116 can be cascaded to a maximum of 128 compatible KVM switches [ see the KVM compatibility list ] allowing control for a maximum of 1024 computers. To allow for ease of installation and compact 1U rack mounting, the KN2116 uses a high density cabling configuration consisting of standard RJ45 connectors and CAT5 cables Connecting to PS/2, USB, Sun Legacy, Sun USB, or Serial devices is merely a matter of selecting the correct CPU adapter [see the accessories list for available selections]. ATEN's proprietary video technology allows servers to be placed up to 120 feet away from the KN2108 while maintaining a video resolution up to 1280 x 1024 @ 60Hz which eliminates the need for KVM extenders. Combining the KN2116 with Aten's Power Distribution Unit (PN0116 / PN0116), the KN2108 allows administrators not only to manage, but also shut down and reboot their servers from an internetconnection Your choice of two functionally identical client applications will allow your work station to communicate with the KVM , one is a universal Java client that will work with any Java enabled OS, or if you prefer, a Windows only client (the work station must be a Windows OS). Because the KVM intercepts and interprets the keyboard and mouse signals the KVM will work with practically any operating system installed on your servers. Server selection can be accomplished in one of four methods [either locally or remotely] 1- Hot key - Keyboard sequence to directly access a port 2- On Screen Display (OSD) - Menu interface 3- Scan - Stop on the desired port 4- Direct "Go to" from the Panel array mode [Panel Array mode displays up to eight serverssimultaneously in one display window] clicking on the desired Panel takes you to that server The unit is password protected using a three level log on: multi-administrator; multi-user; multi-viewer. Ports denied access to a particular user are not displayed in the OSD or Panel Array modes. Advanced security and encryption technologies include 1024 bit RSA; 56 bit DES; 256 bit AES; 128 bit SSL, and RADIUS Support

• Remote access via LAN, WAN, or the Internet
• Supports 3 bus sessions (1 local; 2 Remote) - 3 different users can access 3 different ports at the same time
• Control up to 64 computers by cascading
• Internet browser access; Windows client and Java client provided; Java client works with all operation systems
• Multi-session visual capability (Panel Array Model) - 4/8/16 Windows on screen display with high performance video capturing algorithm
• Up to 64 user accounts
• Supports Radius server
• 3-level password security
• Advance security features, including remote and advanced encryption technologies -1024 bit RSA; 56 bit DES; 256 bit AES; and 128 bit SSL
• Flash upgradeable firmware
• Supports all major server platforms and VT100 based serial devices
• Supports 10Base-T, 100Base-T, TCP/IP, HTTP
• High video resolution: up to 1280 x 1024 @ 60Hz
• For mounting versatility the unit can be split front to rear
